Chrysler 300 Gen2 | 2011-2023

courtesy of
stevegolf

Trim:

Make:

Chrysler

Model:

300

Model Years:

2011 - 2023

Production Years:

2011 - 2023

Model Years (Trim):

2016

Production Code:

Trim Levels:

Anniversary Edition, C, C Platinum, Limited, S, SRT-8, Touring

Base Price:

$35,255 (2016)

Fully Loaded:

# Made (by trim level):

Total Produced:

271,247 units

Class:

Full-size Luxury

Body Style:

Sedan

Layout:

Front-engine/RWD/AWD

Interior Volume:

106.3 cu ft

Trunk Volume:

16.3 cu ft

Front Head/Leg Room:

36.9 inches/ 41.8 inches

Rear Head/Leg Room:

36.9 inches/ 40.1 inches

Engine Type:

Displacement:

3.0 Liters

Engine Code:

A630

Years Offered:

2011+

Countries Available:

# Produced:

Max Power @ RPM:

Max Torque @ RPM:

Forced Induction:

Honeywell VGT 2056

Max Boost Pressure:

Redline:

HP/L:

Bore/Stroke:

83mm/92mm

Compression Ratio:

15.5:1

Firing Order:

Block Material:

Vermicular Graphite Iron

Head Material:

Aluminum

Engine Management:

Fuel Delivery System:

Direct-injection

Recommended Octane:

Valvetrain Type:

DOHC

# of Valves:

24 valves

Fuel Type:

Diesel

Fuel Capacity:

18.5 gal

Recommended Oil:

Oil Volume:

Coolant Volume:

Coolant Type:

Vehicles with this engine

Driveline Type:

Automatic

Transmission Type:

Mercedes-Benz

Transmission Code:

5G-Tronic

1st Gear Ratio/Max RPM/MPH:

2nd Gear Ratio/Max RPM/MPH:

3nd Gear Ratio/Max RPM/MPH:

4th Gear Ratio/Max RPM/MPH:

5th Gear Ratio/Max RPM/MPH:

6th Gear Ratio/Max RPM/MPH:

7th Gear Ratio/Max RPM/MPH:

8th Gear Ratio/Max RPM/MPH:

Final Drive Ratio:

Axle Ratio:

Differential:

Axle Size:

Fluid Type:

236.14

Fluid Capacity:

Reverse Ratio:

Vehicles with this transmission

Platform:

Chrysler LX-platform

Weight:

4,029 lb

Front/Rear:

Steering Type:

Lock to Lock:

Wheel Base:

120.2 inches

Length:

198.6 inches

Width:

75 inches

Height:

58.5 inches

Front Track:

63.4 inches

Rear Track:

63.8 inches

Front Suspension Type:

Control-arm suspension

Rear Suspension Type:

Multi-link suspension

Front Brakes:

Discs

Front Disc/Drum Size:

Front Caliper Size:

Rear Brakes:

Discs

Rear Disc/Drum Size:

Rear Caliper Size:

Fuel Capacity:

ABS:

Yes

Stability Control:

Yes

Stability Control Defeat:

Traction Control:

Yes

Hub Diameter:

Wheel Size Front:

18 in x 7.5 in

Wheel Size Rear:

18 in x 7.5 in

Tire Type:

All season

Front Tires:

P225/60TR18

Rear Tires:

P225/60TR18

Bolt Pattern:

Stock Offset:

Camber:

Toe:

0-30 MPH:

0-60 MPH:

0-100 MPH:

0-150 MPH:

0-200 MPH:

1/4 Mile @ MPH:

Top Gear 30-50 MPH:

Top Gear 50-70 MPH:

Top Speed:

Top Speed Limited By:

Braking 60-0 MPH:

Braking 100-0 MPH:

Skidpad:

Idle dBA:

Full Throttle dBA:

Cruise dBA @ MPH:

Lb/Hp:

EPA City/Highway:

19 mpg/ 31 mpg

Range:

351.5 mi - 573.5 mi

Turning Circle:

38.9 ft

Cd:

0.32
