Fuel by ACW

3 minute read

Fuel

Compliments of ACW @ http://ls1tech.com

6-15-2005

LT1 fuel filter (93-97) (AC-Delco #GF578) = 25121293
LT1 front flexible fuel supply lines (94-97) = 10258441
LT1 fuel pump relay (93-97) = 12193601
LT1 round retainer for fuel lines at side of throttle body (94-97) = 12048089
LT1 fuel injector (94-97) = 17124248
LT1 fuel rail kit with parts for return line (93-97) = 17113095
LT1 fuel rail (94-97), RH = 17113251
LT1 fuel rail seal kit (94-97) (AC-Delco #217-449) = 17113086
LT1 fuel rail crossover tube kit (94-97) = 17113092
LT1 fuel pressure regulator (93) (AC-Delco #217-370) = 17107491
LT1 fuel pressure regulator (94-95) = 17091221
LT1 fuel pressure regulator (96-97) = 17091947
LT1 fuel pressure regulator vacuum hose (94-97) = 10216948
LT1 fuel injector o-ring seal kit (94-97) (AC-Delco #217-1379) = 17113544
LT1 fuel tank (93-97) (metal, 15.5 gallons) = 10269093
LS1 fuel filter = 25121942
LS1 fuel injector (98) = 12533952
LS1 fuel injector (99-00) = 12456154
LS1/LS6 fuel injector (01) = 12482704
LS1/LS6 fuel injector (02, at 28#; used in Corvette Z06) = 12561462
LS1/LS6 fuel injector from C5R racecar (42# at LS1/LS6 58psi pressure) = 24508208
LS1 fuel tank filler hose (99-02) = 10409866
LS1 fuel tank filler pipe (99-02) = 10409867
LS1 fuel tank (98) (metal, 15.5 gallons) = 10293379
LS1 fuel tank (99-02) (plastic, 16.8 gallons) = 10422917
LS1 fuel tank pressure sensor assembly = 25323815
LS1 fuel pressure regulator = 12555909
LS1 fuel pump (98) = 253193351
LS1 fuel pump (99-02) = 25338871
LS1 fuel rails (98-02) (AC-Delco #217-1401) = 12562815
LS1 fuel rail cover (dual slots) (from 97-98 Corvette, black, red letters), LH = 12559261
LS1 fuel rail cover (dual slots) (from 97-98 Corvette, black, red letters), RH = 12556455
LS1 fuel rail cover (from 99-02 Corvette, black, red letters), LH = 12561503
LS1 fuel rail cover (from 99-02 Corvette, black, red letters), RH = 12561502
LS6 fuel rail cover (from 01-02 Corvette Z06, red, black letters), LH = 12564257
LS6 fuel rail cover (from 01-02 Corvette Z06, red, black letters), RH = 12564258
fuel line protectors (93-02) = 10232676
LS1 schrader valve at end of fuel rail = 25532663
Evap Control Valve (evaporative emissions canister purge solenoid valve) = 1997278
fuel tank filler door bumper (on door) (need 1 of these) (93-02) = 10172357
fuel tank filler door bumper (on pocket) (need 2 of these) (93-02) = 10257216
gas cap ('fuel tank filler cap') (93-97) (AC-Delco #GT174) = 10164142
gas cap (with tether) (98) (AC-Delco #GT222) = 22616291
gas cap (with long tether) (99-02) = 22616287 (discontinued for short version)
gas cap (with short tether) (99-02) (A-D #GT261) = 25757560 (form. 22660003, 22616286)
gas cap (without tether) (99-02) (AC-Delco #12F58) = ?
locking gas cap (99-02) (A-D #GT270 or 12F31L) = 22720375 (formerly 22660006, 22616294)
locking gas cap (98) - can use the above one, cut/grind down the tabs a little, should fit
