Acura ZDX | 2010-2013

courtesy of
diyauto

Trim:

Make:

Acura

Model:

ZDX

Model Years:

2010 - 2013

Production Years:

2009 - 2013

Model Years (Trim):

Production Code:

Trim Levels:

Base, Premium

Base Price:

$45,495

Fully Loaded:

$57,995

# Made (by trim level):

Total Produced:

6,117 units

Class:

Mid-size Luxury Crossover

Body Style:

SUV

Layout:

Front-engine/AWD

Interior Volume:

Trunk Volume:

26.3 cu ft

Front Head/Leg Room:

38 inches/ 42.6 inches

Rear Head/Leg Room:

35.3 inches/ 31.1 inches

Designers:

Michelle Christensen

Assembly Plants:

Honda of Canada Manufacturing

Engine Type:

Displacement:

3.7 Liters

Engine Code:

J37A5

Years Offered:

Countries Available:

# Produced:

Max Power @ RPM:

300 HP @ 6,300 RPM

Max Torque @ RPM:

270 lb-ft @ 4,500 RPM

Forced Induction:

Max Boost Pressure:

Redline:

HP/L:

81.1

Bore/Stroke:

90mm/96mm

Compression Ratio:

11.2:1

Firing Order:

Block Material:

Head Material:

Engine Management:

Fuel Delivery System:

PGM-FI

Recommended Octane:

Premium

Valvetrain Type:

SOHC VTEC

# of Valves:

24 valves

Fuel Type:

Gas

Fuel Capacity:

21 gal

Recommended Oil:

Oil Volume:

Coolant Volume:

Coolant Type:

Driveline Type:

Automatic

Transmission Type:

Transmission Code:

1st Gear Ratio/Max RPM/MPH:

3.38

2nd Gear Ratio/Max RPM/MPH:

2.11

3nd Gear Ratio/Max RPM/MPH:

1.49

4th Gear Ratio/Max RPM/MPH:

1.06

5th Gear Ratio/Max RPM/MPH:

0.76

6th Gear Ratio/Max RPM/MPH:

0.56

7th Gear Ratio/Max RPM/MPH:

n/a

8th Gear Ratio/Max RPM/MPH:

n/a

Final Drive Ratio:

4.25

Axle Ratio:

Differential:

Axle Size:

Fluid Type:

Fluid Capacity:

Reverse Ratio:

2.26

Vehicles with this transmission

Platform:

Weight:

4,410 lb

Front/Rear:

Steering Type:

Lock to Lock:

Wheel Base:

108.3 inches

Length:

192.4 inches

Width:

78.5 inches

Height:

62.8 inches

Front Track:

67.7 inches

Rear Track:

67.7 inches

Front Suspension Type:

Magneto Rheological Shocks, MacPherson strut, Independent suspension, stabilizer bar

Rear Suspension Type:

Magneto Rheological Shocks, Multi-link, Independent suspension, stabilizer bar

Front Brakes:

Vented discs

Front Disc/Drum Size:

Front Caliper Size:

Rear Brakes:

Solid discs

Rear Disc/Drum Size:

Rear Caliper Size:

Fuel Capacity:

ABS:

Yes

Stability Control:

Yes

Stability Control Defeat:

Traction Control:

Yes

Hub Diameter:

Wheel Size Front:

19 x 8.5 in

Wheel Size Rear:

19 x 8.5 in

Tire Type:

All season

Front Tires:

P255/50R19 103H

Rear Tires:

P255/50R19 103H

Bolt Pattern:

Stock Offset:

Camber:

Toe:

0-30 MPH:

0-60 MPH:

0-100 MPH:

0-150 MPH:

0-200 MPH:

1/4 Mile @ MPH:

Top Gear 30-50 MPH:

Top Gear 50-70 MPH:

Top Speed:

Top Speed Limited By:

Braking 60-0 MPH:

Braking 100-0 MPH:

Skidpad:

Idle dBA:

Full Throttle dBA:

Cruise dBA @ MPH:

Lb/Hp:

EPA City/Highway:

16 mpg/ 23 mpg

Range:

336 mi - 483 mi

Turning Circle:

38.4 ft

Cd:
